Toggle Press KHP
Products
TO PUNCH THE SPECIMEN WITH A BELL HAMMER FOR FURTHER TESTING (E.G., HOT SET TEST)
Device details
- Sample preparation according to IEC 60811 -501, -507
- Available with a 75 mm (2.95″) or 50 mm (2.97″) bell instrument
- For inspecting cable sheaths in laboratories
- As preparation for further tests
- Applicable for all cable types
- The cutting surface is also available individually
Technical details
- Dimensions (WxDxH) 156 x 292 x 475 mm 6,14 x 11,5 x 18,7 inches
- Weight 10,75 kg / 23,7 lbs
- Material Aluminium, steel, cutting surface: PVC
- Punch blade in stainless steel with automatic sample ejection
- Moulding force 8 kN
